Equipment
Mill Station #1: Southwestern Industries Comet 3KVH
• 2-axis CNC, 3-axis DRO• 3 HP spindle motor and R8 spindle taper
Mill Station #2: South Bend 2VS
• Manual, 3-axis DRO• 3 HP spindle motor and R8 spindle taper
Lathe Station #1: Turn Master PHL 1880
• Manual
Lathe Station #2: Southwestern Industries TRAK TRL 1630SX
• Operate in CNC or Manual mode• ProtoTRAK SLX CNC
•16” swing over bed, 30” between centers
Drill Press: Wilton VSG Twenty
• 2 HP motor• Split Head
• 4 ½“ Column
• Heavy Duty Head and Table Raisers
• Hardened Chrome Quill
Vertical Band Saw: Dake Johnson Model VH-24
• 1.5 horsepower• Blade speed of 50-5000 fpm
• Maximum work height 12’’
• Work table size 24" x 36"
Horizontal Band Saw: Dake Johnson Model J-10
• Cutting capacity 10” rounds, 18” flats• Bed Work Area 11” x 18”
• 1 HP drive motor
• Blade Speeds 50, 90, 160, and 270 fpm
Tennsmith Sheet Metal Brake HBU4812
• Max Capacity, mild steel – 12 Gauge• Max Capacity, stainless steel – 16 Gauge
• Bending length – 48 ¼“
• Maximum lift of beam – 1 ½“
• Maximum depth of box – 4”
Tennsmith Sheet Metal Shear T5216
• Max. Shearing Capacity Mild Steel – 16 Gauge• Max. Shearing Capacity Stainless Steel – 20 Gauge
• Max. Cutting Length – 52 ¼“
• Back Gauge Range – 30”
• Front Gauge Range – 37”
Sheet Metal Notcher Model 16-18
• Max. Capacity Notching, Mild Steel – 16 Gauge• Max. Capacity Piercing, Mild Steel – 18 Gauge
• Notch – 6 x 6 in. x 90 degrees
Water Jet System: GlobalMAX 1508
The GlobalMAX 1508 has a cutting bed of 2’7” x 5’0” that is able to cut virtually any material.
Welding Station
• Tig – Syncrowave 250• Mig – Millermatic 211 – Auto-Set
• Arc Welder – IdealArc DC400 Multipurpose Welder
Material Inspection Station
Belt/Disc Sander
• 6" wide belt and 9" diameter disc• 1 horsepower
• 3450 rpm
Trinco Sand Blast System
• 38” W x 64” H x 25” D• Working Dimensions – 36” W x 23” High x 24” Deep
Hand Tools
• General Hand tools• Mechanic Socket and Wrench sets
• Layout and Measuring tools
• Many others available upon request
Other Tools and Equipment
• Drills/Drivers• Circular, Jig and Reciprocating saws
• Miter saw work station
• Sanders
• Finishing/Post-processing tools
• Heat guns
• Electronic measuring devices
• Other tools available upon request
Electronics Work Station
• Digital Multimeter• Function Generator
• Soldering Station
• Oscilloscope
• Power supply
• Various gauge wire and test probes
